Votronic Charging-Booster VCC 12V 45A

Charging-Converter VCC 12V 45A with galvanic insulation

Perfect charging even on short distances
Votronic Charging-Boosters are made for optimised and quick charging of supply batteries by the onboard generator during driving.



The boosters are easily installed into the charge cabling of the battery. They are increasing the charging voltage and do regulate the quick and soft maximum charging of Acid-, Gel or AGM - batteries realized by IU1oU2 charging curves. LEDs give permanent information of the operating state of the unit. Control input for fully automatic controlled operation is ignition, D+ engine running.

Tech. Data Charging - Converter VCC 1212-45 IUoU

• Charging capacity 12 V / 45 A
• max. current 63 A
• Input Voltage 11-16 V
• U1-charge voltage 12 V - 13,3 V
• Battery capacity 90 - 300 Ah / 400 Ah max.
• Charging type IU1oU2
• Batterytype 4x adjustable Acid, Gel, AGM, AGM-IU1oU2, LiPoFe
• Connections for Temperature Sensor / Sensorcable / Remote Control
• Dimensions (WxHxD) 138 x 74 x 265 mm ¹
• Weight 1700 g
• Manufacturer code 3306

¹ Dimensions incl. mounting flanges, without connections

CE, E-Test (EMV/Automotive Regulations)
Package content:  charger, Temp.sensor, manual
